The MWIR (Mid-wave Infrared) series of cooled infrared detectors are sensitive to the medium wave infrared range of 3.7μm±0.2μm～4.8μm±0.2μm, ensuring effective detection and imaging of thermal radiation. They use HgCdTe (Mercury Cadmium Telluride) as the sensitive material to deliver superior thermal imaging with excellent sensitivity and accuracy. They are available in a variety of resolutions and pixel sizes to meet diverse needs. The cooled MWIR infrared detectors have resolutions of 128x128, 320x256, 640x512, and 1280x1024, providing a range of detail levels from compact to high-definition imaging, and versatile pixel sizes of 30μm, 25μm, 15μm, 12μm, 10μm, and 7μm to balance between spatial resolution and sensitivity for your specific application requirements.

Guide Infrared has mastered the complete manufacturing process of cooled infrared detector, such as element purification, substrate, epitaxy, FPAs, ROIC, coolers, package and testing etc. These cooled MWIR infrared detectors have already achieved continuous supply in various mid-to-high-end thermal imaging fields.

With response range covering medium wave, the cooled MCT infrared detectors have high thermal sensitivity, high quantum efficiency and good response rate. By experiencing unparalleled thermal imaging capability with our cutting-edge technology, cooled MWIR systems can detect very low levels of infrared radiation, making them ideal for applications in low-light or challenging environments. The cooled infrared detectors can also respond quickly to changing infrared signals, making them suitable for dynamic environments where rapid detection is necessary. With proper handling and maintenance, the cooled HgCdTe infrared detectors exhibit good stability and longevity, providing reliable performance over time.

Our cooled MWIR infrared detectors are engineered for high precision and durability, making them perfect for applications with high performance and accuracy. They can be a preferred choice in various high-performance sensing and imaging applications such as long-range surveillance systems, eo ir systems, uav payloads, handheld thermal imagers, gas leakage detection cameras, and other demanding applications.
